HFJV1-E2450-L21RL Rj45 Vertical With Magnetics 1x1 10/100BASE-T LPJD5011BENL

Name: HFJV1E2450L21RL Rj45 Vertical With Magnetics 1x1 10100BASET LPJD5011BENL
Brand: LINK-PP
Price: 0.09 USD

Brand Name : LINK-PP

Model Number : HFJV1-E2450-L21RL

Certification : UL,ROHS,Reach,ISO

Place of Origin : GuangDong, China

MOQ : 50/500/1000/25K

Price : $0.09-$1.85

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : 54PCS/Tray,24Trays=37*30*30CM=1296PCS=10KG/Carton

part Number : HFJV1-E2450-L21RL

Mass Production : LPJD5011BENL

Original Munafactuer : LINK-PP

Application : 1x 10/100 Base-T

Termination : Solder

LEDs : Optional

Mounting : Vertical

Samples : Available

Contact Now

HFJV1-E2450-L21RL Rj45 Vertical With Magnetics 1x1 10/100BASE-T LPJD5011BENL

FastJack ™ 1x1 Vertical 10/100BASE-T RJ45

1. 10/100BASE-T Ethernet RJ45
2. IEEE802.3u Compliant
3. 350uH min OCL at 8mA DC Bias Across the Full Temp Range
4. 30µ” Gold Plating (min) on Contacts
5. 100% Compliance Testing
6. 1500Vrms Hi-Pot

Electrical Specifications @25℃
1.OCL: 350uH Min
@100KHz,0.1V,8mADC BIAS
2.Turns Ratio(%%P2%):
TX = 1CT∶1CT RX = 1CT∶1CT
3.Insertion Loss:
0.1-100MHz:-1.1dB Max
4.Return Loss(dB Min):
0.5-30MHz:-18 40MHz:-15.5
50MHz:-13.6 60-80MHz:-12
5.Crosstalk(dB Typ):
0.1-100MHz:-40
6.Common Mode Rejection(dB Typ):
0.1-30MHz:-50 30-60MHz:-40
60-100MHz:-35
7.Isolation Voltage: 1500Vrms
8.Operating Temperature: -40℃～+85℃

HFJV1-E2450-L21RL Rj45 Vertical With Magnetics 1x1 10/100BASE-T LPJD5011BENL
